Two-Panel Classic

Durable and Reliable

At KLEFER we understand the importance of longevity in lift equipment. For this reason, the Two-Panel Classic door is manufactured using high-quality and robust materials and components that are resistant to wear, corrosion, and impacts, suitable for the high demanding industrial segment. The innovative features of KLEFER’s semi-automatic doors guarantee smooth operation and easy maintenance, providing peace of mind and long-lasting performance.

Advantages and Features

– In compliance with EN 81.1/2, EN81.20/50, EN81.58 (E120-EW60)
– Αvailable in powder coated paint
– Available in stainless steel AISI 441, 304, 316L
– Customized side and upper frame, depending on the shaft opening
– Certified mechanical & electric locks
– Εxternal reinforced hinges
– Low pit safety switches (EN 81.21)
– Protective paint film & top quality packaging

– Special structure for doors ≥ 6,5m²

Category:

Description

Recommended Use

Standard

INDUSTRIAL
TRANSPORT
HOSPITALS
COMMERCIAL

The recommended use is indicative only, and various factors such as the purpose of use, the hourly and annual number of cycles and the lift speed should be taken into consideration.

Configurator
Type Clear Opening Clear Height
C2
950mm – 2750mm
2000mm – 3000mm
E120-EW60 Clear Opening Clear Height
C2
950mm – 1700mm
2000mm – 2400mm
Characteristics
Advantages & Features
Standard Equipment
  • Door Closers
  • Wired Safety Glass
  • Anodized Aluminum Handles
  • Aluminum Vision Frames
  • Ral 7032 (Structure - Gloss)
  • Certified Mechanical Lock
  • Side Frames: 125x50
  • Upper Frame: 125x50
  • External Reinforced Hinges
  • Fixings
  • Divided Frame*
  • Protective Paint Film
  • Heady Duty Packaging

     *Depending on C.O, C.H & frame dimensions.

Customization
  • Custom side & upper frame
    dimensions to facilitate the installation
PU Foam Core
  • Better painting surface due to absence of welds.
  • Lighter panel up to 40kg in case of stainless steel sheet
  • Soundproof insulation & improved acoustics during both opening and closing.

     *(PU application depends on C.O, C.H frame dimensions & finishing)

Installation
  • Pre-adjusted and assembled* door to simplify installation
  • Easily adjusted closing spring.

     *(depending on C.O & C.H)

Door Opening

     Door Opening

  • Independent door panel opening
  • Leading Panel (Right/Left panel first)

     Door Opening Angle

  • With spring closing system = 95°
  • Without spring closing system = 180°
Roller Lever Position
  • Door header left side (default)
  • Door header right side
  • Door frame on left side (height as requested)
  • Door frame on right side (height as requested)
Heavy Duty

     Heavy Duty structure ≥ 6,5m²

     Conditions:

  • C.O x C.H ≥ 6,5m2
  • CO ≥ 3000 & CH ≥ 2000
  • CO ≥ 1800 & CH ≥ 3000

     Characteristics

  • Upper & Side Frames: 150mm
  • Depth: 64mm
  • Panels: 3mm
  • Frames: 2mm
  • Hinges: Reinforced
Options
Locks
  • Mechanic (IT-Electrometal, Kronenberg, Schmersal)
  • Electric (Kronenberg)
LOP cut outs
  • Available
Unlocking Kit
  • Available
Closing System
  • Spring (default)
  • DITEC (button, actuated system) - optional
Handles
  • Anodized Aluminum (default)
  • St.St Satin bar [Z1]
  • St.St Gold Satin bar [Z1]
  • St.St Satin bar, 1800mm [Z2]
Panels
  • Metal Sheet (blind)
  • Small Vision (Wired or transparent glass)
Protection
IP20
  • Gea Zita Lock [Mechanic]
IP40
  • Kronenberg Lock [Mechanic & Electric]
IP54
  • Kronenberg [Mechanic & Electric]
IP67
  • Kronenberg [Mechanic]
Certification
2014/33/EU
  • Safety Component used on Classic Blind door meets 2014/33/EU standards.
EN 81.1/20 & 81.20/50

      EN 81.20/50

  • Clear Opening: 950mm - 1700mm
  • Clear Height: 2000mm - 2400mm
  • with leading panel
  • with transparent safety glass
  • Saloon type do not comply with EN81.20/50
  • Available with transparent safety glass on EN81.20/50

      EN 81.1/2

  • Clear Opening: 950mm - 2750mm
  • Clear Height: 2000mm - 3000mm
  • with leading panel or saloon type
EN 81.21
  • Bi-stable low pit contact
EN 81.58

     Fire Resistance: E120 - EW60

  • Clear Opening: 950mm - 1700mm
  • Clear Height: 1700 - 2400mm
  • Side Frames: 100mm - 150mm
  • Upper Frame: 125mm - 150mm
  • Saloon type do not comply with E120-EW60
  • E120-Ew60 on 81.20/50 is valid with blind panels only.
Finishing
Powder Coating
  • Wide range of high-quality
    structure gloss Ral finishings.
Stainless Steel
Wooden Coated
  • 2-Panel Classic is not available in wooden coating finishing.
Compatibility
Automatic Doors

     Models (81.1/2):

  • 40/10PM, 50/11PM, 40/10VF, 50/11VF

     Cam options:

  • Side acting lateral cam
  • Inverted lateral cam
  • Fixed cam
  • Fixed flexible cam
Automatic Bus Folding doors
  • Models:
    G3, G5, G5EM

     Cam options:

  • Lateral retractable
